AT29BV040A-20TU

PEROM, TSOP32, 3-volt, Single Supply Voltage, Software Protected Programming

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.17~1.30 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.17~1.30

PartNumber:: AT29BV040A-20TU

Brand:: ATMEL Corporation - ATMEL | Pack: TSOP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Lisa's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-12-16

From Other Seller

Part Number:AT29BV040A-20TU
US $1.17 - 1.30
ECA1HHG4R7

US $10.00 - 10.00 / Piece
(0) Remove
AT25256AW-10SU-2.7

US $0.65 - 1.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AT29BV040A-20TU is a 3-volt-only in-system Flash Programmable and Erasable Read Only Memory (PEROM). Its 4 megabits of memory is organized as 524,288 words by 8 bits. Manufactured with Atmel’s advanced nonvolatile CMOS EEPROM technology, the AT29BV040A-20TU offers access times to 200 ns, and a low 54 mW power dissipation. When the AT29BV040A-20TU is deselected, the CMOS standby current is less than 50 μA. The device endurance is such that any sector can be written to in excess of 10,000 times. The programming algorithm is compatible with other devices in Atmel’s 2.7-volt-only Flash memories.

Parametrics

AT29BV040A-20TU absolute maximum ratings: (1)Temperature Under Bias: -55 to +125℃; (2)Storage Temperature: -65 to +150℃; (3)All Input Voltages (including NC Pins) with Respect to Ground: -0.6V to +6.25V; (4)All Output Voltages with Respect to Ground: -0.6V to VCC + 0.6V; (5)Voltage on A9 (including NC Pins) with Respect to Ground: -0.6V to +13.5V.

Features

AT29BV040A-20TU features: (1)Single Supply Voltage, Range 2.7V to 3.6V; (2)Single Supply for Read and Write; (3)Software Protected Programming; (4)Fast Read Access Time: 200 ns; (5)Low Power Dissipation: 15 mA Active Current; 50 μA CMOS Standby Current; (6)Sector Program Operation: Single Cycle Reprogram (Erase and Program); 2048 Sectors (256 Bytes/Sector); Internal Address and Data Latches for 256 Bytes; (7)Two 16K Bytes Boot Blocks with Lockout; (8)Fast Sector Program Cycle Time 20 ms Max.; (9)Internal Program Control and Timer; (10)Minimum Endurance 10,000 Cycles; (11)CMOS and TTL Compatible Inputs and Outputs; (12)Green (Pb/Halide-free) Packaging Option.
