IDTQS32XVH245Q2G8

40-QVSOP, 2.5V / 3.3V, 16-bit high bandwidth bus switch, Low I/O capacitance

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.63~0.70 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.63~0.70

PartNumber:: IDTQS32XVH245Q2G8

Brand:: Integrated Device Technology - IDT | Pack: SSOP | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Lisa's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-12-16

From Other Seller

Part Number:IDTQS32XVH245Q2G8
US $0.63 - 0.70
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
HCPL-7800A

US $2.50 - 4.10 / Piece
(0) Remove
Quantity:

piece

Product Summary

The IDTQS32XVH245Q2G8 is a high bandwidth, 16-bit bus switch. The device has very low ON resistance, resulting in under 250ps propagation delay through the switch. The IDTQS32XVH245Q2G8 can be turned ON under the control of the LVTTL-compatible Output Enable (OEx) signal for bidirectional data flow with no added delay or ground bounce. In the ON state, the switches can pass signals up to 5V. The applications of the IDTQS32XVH245Q2G8 are Hot-swapping, 10/100 Base-T, Ethernet LAN switch, Low distortion analog switch, Replaces mechanical relay, ATM 25/155 switching.

Parametrics

IDTQS32XVH245Q2G8 absolute maximum ratings: (1)SupplyVoltage to Ground:–0.5 to +4.6 V; (2)DC Switch Voltage VS:–0.5 to +5.5 V; (3)DC Input Voltage VIN:–0.5 to +5.5 V; (4)AC Input Voltage (pulse width ≤20ns):–3 V; (5)DC Output Current (max. sink current/pin):120 mA; (6)Storage Temperature:–65 to +150℃.

Features

IDTQS32XVH245Q2G8 features: (1)N channel FET switches with no parasitic diode to VCC; (2)Isolation under power-off conditions; (3)No DC path to VCC or GND; (4)5V tolerant in OFF and ON state; (5)5V tolerant I/Os; (6)Low RON - 4Ω typical; (7)Flat RON characteristics over operating range; (8)Rail-to-rail switching 0 - 5V; (9)Bidirectional dataflow with near-zero delay: no added ground bounce; (10)Excellent RON matching between channels; (11)VCC operation: 2.3V to 3.6V; (12)High bandwidth - up to 500MHz; (13)LVTTL-compatible control Inputs; (14)Undershoot Clamp Diodes on all switch and control Inputs; (15)Low I/O capacitance, 4pF typical; (16)Available in 40-pin QVSOP package.
