JS28F160C3TD70

Advanced+ Boot Block Flash Memory, 16M-Bit, 70ns, 48-Pin TSOP, Flexible SmartVoltage Technology

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.59~0.65 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.59~0.65

PartNumber:: JS28F160C3TD70

Brand:: Intel Corporation - Intel | Pack: TSSOP | D/C: 06+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Lisa's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-12-16

From Other Seller

Part Number:JS28F160C3TD70
US $0.59 - 0.65
LM64P101

US $240.00 - 300.00 / Piece
(0) Remove
AT24C02BN-SH-T

US $0.08 - 0.15 / Piece
(0) Remove
Quantity:

piece

Product Summary

The JS28F160C3TD70 is an Advanced+ Book Flash Memory (C3) device, manufactured on Intel’s latest 0.13 um and 0.18 um technologies, represents a feature-rich solution for low-power applications. The JS28F160C3TD70 incorporates low-voltage capability (3 V read, program, and erase) with high-speed, low-power operation. Flexible block locking allows any block to be independently locked or unlocked. The JS28F160C3TD70 supports read-array mode operations at various I/O voltages (1.8 V and 3 V) and erase and program operations at 3 V or 12 V VPP.

Parametrics

JS28F160C3TD70 absolute maximum ratings: (1)Extended Operating Temperature:–40℃ to +85℃; (2)Storage Temperature:–65℃ to +125℃; (3)Voltage On Any Pin (except VCC and VPP) with Respect to GND:-0.5V to +3.7V ; (4)VPP Voltage (for Block Erase and Program) with Respect to GND:-0.5V to +13.5V ; (5)VCC and VCCQ Supply Voltage with Respect to GND:–0.2V to +3.6V; (6)Output Short Circuit Current:100 mA.

Features

JS28F160C3TD70 features: (1)Eight 4 Kword blocks, top or bottom parameter boot; (2)Up to 127 x 32 Kword blocks; (3)Fast program suspend capability; (4)Fast erase suspend capability; (5)Flexible SmartVoltage Technology: 2.7 V to 3.6 V read/program/erase, 12 V for fast production programming; (6)1.65 V to 2.5 V or 2.7 V to 3.6 V I/O Option:Reduces overall system power; (7)High Performance:2.7 V to 3.6 V: 70 ns max access time; (8)Lock/unlock any block; (9)Full protection on power-up; (10)Write Protect(WP#) pin for hardware block protection; (11)Intel Flash Data Integrator; (12)Supports top or bottom boot storage, streaming data (for example, voice); (13)Intel Basic Command Set; (14)Common Flash Interface.
