Product Summary
The VSC1237XSR is a complete highperformance multiplexer chip set designed for 9.9-12.5 Gbps applications, including SONET OC-192, SDH STM-64, 10GbE, G.975, G.709 and offering enhanced capabilities specifically designed to address the needs of Ultra Long Haul (ULH) and Long Haul (LH) fiber optic transmission systems. The VSC1237XSR easily surpasses the jitter requirements for SONET/SDH transmission systems. Integrated phase locked loop circuits, including VCOs, are used for high speed clock generation, jitter filtering and low-speed data transfer. The applications of the VSC1237XSR include: SONET OC-192, SDH STM-64 Systems, 10GbE, G.975, G.709 and Proprietary FEC Systems, Long Haul / Ultra Long Haul Transmission Systems, Line Cards, Transponders.
Parametrics
VSC1237XSR specifications: (1)LVDS Compatible Low-speed I/O; (2)-5 to +90℃ Case Temperature Range.
Features
VSC1237XSR features: (1)16:1 Data Multiplexer; (2)PLL Based Clock Multiplier; (3)Integrated Jitter Filter PLL; (4)Full-rate/Half-rate Clock Outputs; (5)Flexible PLL Based Parallel Data Clocking; (6)Selectable Bit-order and Phase Reversal; (7)Selectable Low Phase Noise VCOs; (8)Surpasses SONET/SDH Jitter Generation/Transfer Requirements.
