Product Summary
The AD8532ARZ is a dual rail-to-rail input and output single-supply amplifier featuring 250 mA output drive current. This high output current makes these amplifiers excellent for driving either resistive or capacitive loads. AC performance is very good with 3 MHz bandwidth, 5 V/ms slew rate and low distortion. All are guaranteed to operate from a 3 volt single supply as well as a 5 volt supply. The very low input bias currents enable it to be used for integrators, diode amplification and other applications requiring low input bias current. Supply current is only 750 mA per amplifier at 5 volts, allowing low current applications to control high current loads.
Parametrics
The AD8532ARZ absolute maximum ratings:(1)Supply Voltage (VS) is 7 V. (2)Input Voltage is GND to VS. (3)Differential Input Voltage is ±6 V. (4)Storage Temperature Range is -65℃ to +150℃. (5)Operating Temperature Range is -40℃ to +85℃. (6)Junction Temperature Range is -65℃ to +150℃. (7)Lead Temperature Range (Soldering, 60 sec) is 300℃.
Features
The AD8532ARZ features:(1)Single-Supply Operation: 2.7 Volts to 6 Volts. (2)High Output Current: +/-250 mA. (3)Low Supply Current: 750 uA/Amplifier. (4)Wide Bandwidth: 3 MHz. (5)Slew Rate: 5 V/us. (6)No Phase Reversal. (7)Low Input Currents. (8)Unity Gain Stable. (9)Rail-to-Rail Input and Output.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 AD8532ARZ |
|
IC OPAMP GP R-R CMOS 3MHZ 8SOIC |
Data Sheet |
|
|
||||||||||||||||||||
|
AD8532ARZ-REEL |
|
IC OPAMP GP R-R CMOS 3MHZ 8SOIC |
Data Sheet |
|
|
||||||||||||||||||||
|
AD8532ARZ-REEL7 |
|
IC OPAMP GP R-R CMOS 3MHZ 8SOIC |
Data Sheet |
|
|
||||||||||||||||||||
