Product Summary

The LMD18245T full-bridge power amplifier incorporates all the circuit blocks required to drive and control current in a brushed type DC motor or one phase of a bipolar stepper motor. The multi-technology process used to build the device combines bipolar and CMOS control and protection circuitry with DMOS power switches on the same monolithic structure. The LMD18245T controls the motor current via a fixed off-time chopper technique. An all DMOS H-bridge power stage delivers continuous output currents up to 3A (6A peak) at supply voltages up to 55V. The DMOS power switch LMD18245T features low RDS(ON) for high efficiency, and a diode intrinsic to the DMOS body structure eliminates the discrete diodes typically required to clamp bipolar power stages. An innovative current sensing method eliminates the power loss associated with a sense resistor in series with the motor. The applications of the device include n Full, half and microstep stepper motor drives, Stepper motor and brushed DC motor servo drives and Automated factory, medical and office equipment.

Parametrics

LMD18245T absolute maximum ratings: (1)DC Voltage at: OUT 1, VCC, and OUT 2: +60V; (2)COMP OUT, RC, M4, M3, M2, M1, BRAKE: +12V; (3)DC Voltage PGND to SGND: ±400mV; (4)Continuous Load Current: 3A; (5)Peak Load Current: 6A; (6)Junction Temperature (TJ(max)): +150℃; (7)Power Dissipation : TO-220 (TA = 25℃, Infinite Heatsink): 25W; TO-220 (TA = 25℃, Free Air): 3.5W; (8)ESD Susceptibility: 1500V; (9)Storage Temperature Range (TS): -40℃ to +150℃; (10)Lead Temperature (Soldering, 10 seconds): 300℃.

Features

LMD18245T features: (1)DMOS power stage rated at 55V and 3A continuous; (2)Low RDS(ON) of typically 0.3W per power switch; (3)Internal clamp diodes; (4)Low-loss current sensing method; (5)Digital or analog control of motor current; (6)TTL and CMOS compatible inputs; (7)Thermal shutdow(outputs off) at TJ = 155℃; (8)Overcurrent protection; (9)No shoot-through currents; (10)15-lead TO-220 molded power package.

Diagrams

LMD18245T diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
LMD18245T/NOPB
LMD18245T/NOPB

National Semiconductor (TI)

Motor / Motion / Ignition Controllers & Drivers H-Bridge Motor Driver W/ Pwm

Data Sheet

0-1: $10.85
1-10: $9.88
10-25: $9.13
25-50: $8.82
Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
LMD18200
LMD18200

Other


Data Sheet

Negotiable
LMD18200T
LMD18200T

National Semiconductor (TI)

Motor / Motion / Ignition Controllers & Drivers

Data Sheet

0-1: $10.66
1-25: $8.96
25-100: $8.24
100-250: $7.52
LMD18200T/LB14
LMD18200T/LB14

National Semiconductor (TI)

Motor / Motion / Ignition Controllers & Drivers

Data Sheet

0-46: $8.96
46-115: $8.23
115-253: $7.51
253-506: $7.02
LMD18200T/LF14
LMD18200T/LF14

National Semiconductor (TI)

Motor / Motion / Ignition Controllers & Drivers

Data Sheet

0-46: $8.96
46-115: $8.24
115-253: $7.52
253-506: $7.03
LMD18200T/NOPB
LMD18200T/NOPB

National Semiconductor (TI)

Motor / Motion / Ignition Controllers & Drivers 3A 55V H-Bridge

Data Sheet

0-1: $10.66
1-25: $8.96
25-100: $8.24
100-250: $7.52
LMD18201
LMD18201

Other


Data Sheet

Negotiable
