M30622F8PFPD5

single-chip 16-bit cmos microcomputer, QFP, -0.3 to 6.5 V, 300mW

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~2.00

PartNumber:: M30622F8PFPD5

Brand:: Renesas Technology Corp - Renesas | Pack: QFP | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Lisa's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-27

From Other Seller

Part Number:M30622F8PFPD5
US $1.00 - 2.00
YL-G709

US $65.00 - 68.00 / Piece
(0) Remove
CM2030-A0TR

US $0.92 - 2.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The M30622F8PFPD5 is a single-chip 16-bit cmos microcomputer. It is built using the high-performance silicon gate CMOS process using a M16C/60 Series CPU core and are packaged in a 80-pin, 100-pin and 128-pin plastic molded QFP. The M30622F8PFPD5 operates using sophisticated instructions featuring a high level of instruction efficiency. With 1M bytes of address space, it is capable of executing instructions at high speed. In addition, the M30622F8PFPD5 contains a multiplier and DMAC which combined with fast instruction processing capability, makes it suitable for control of various OA, communication, and industrial equipment which requires high-speed arithmetic/logic operations. The M30622F8PFPD5 is used in Audio, cameras, office/communications/portable/industrial equipment, automobile, etc.

Parametrics

M30622F8PFPD5 absolute maximum ratings: (1)VCC1, VCC2 Supply voltage: -0.3 to 6.5 V; (2)VCC2 Supply voltage: -0.3 to VCC1+0.1 V; (3)AVCC Analog supply voltage: -0.3 to 6.5 V; (4)Pd Power dissipation: 300mW; (5)Topr Operating ambient temperature: -20 to 85 ℃; (6)Tstg Storage temperature: -65 to 150 ℃.

Features

M30622F8PFPD5 specifications: (1)VCC1, VCC2 Supply voltage(VCC1≥VCC2): 2.7 to 5.5V; (2)AVcc Analog supply voltage: VCC1 V; (3)f(ripple) Power supply ripple allowable frequency: 10MHz; (4)VP-P(ripple) Power supply ripple allowable amplitude voltage: 0.5V; (5)VCC(|△V / △T|) Power supply ripple rising / falling gradient: 0.3V/ms; (6)SVCC Power supply rising gradient: 0.05V/ms.
