MAX3471EUA

Differential Transceiver, 2.5 to 5.5 V, 1.6 μA, SOP, MAX3471EUA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~2.00

PartNumber:: MAX3471EUA

Brand:: Maxim Integrated Products - Maxim | Pack: SOP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Lisa's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-27

From Other Seller

Part Number:MAX3471EUA
US $1.00 - 2.00
TDA7360

US $0.80 - 1.50 / Piece
(0) Remove
AD595AD

US $7.00 - 9.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MAX3471EUA is a 1.6μA, RS-485/RS-422, Half-Duplex, Differential Transceiver for Battery-Powered Systems. It draws only 1.6μA (typical) supply current from a 3.6V supply with the receiver enabled and the driver disabled. Its wide 2.5V to 5.5V supply voltage guarantees operation over the lifetime of a lithium battery. The MAX3471EUA features true fail-safe operation that guarantees a logic-high receiver output when the receiver inputs are open or shorted. The applications of the MAX3471EUA include: Remote Meter Reading, Battery-Powered Differential Communications, Level Translators.

Parametrics

MAX3471EUA absolute maximum ratings: (1)Supply Voltage (VCC): 7V; (2)Control Input Voltage (RE, DE): -0.3V to (VCC + 0.3V); (3)Driver Input Voltage (DI): -0.3V to (VCC + 0.3V); (4)Driver Output/Receiver Input Voltage (A, B): ±10.5V; (5)Receiver Output Voltage (RO): -0.3V to (VCC + 0.3V); (6)Continuous Power Dissipation μMAX (derate 4.5mW/℃ above +70℃): 362mW; (7)Operating Temperature Ranges: -40℃ to +85℃; (8)Storage Temperature Range: -65℃ to +160℃; (9)Lead Temperature (soldering, 10sec): +300℃.

Features

MAX3471EUA features: (1)1.6μA Supply Current with Receiver Enabled; (2)+2.5V to +5.5V Single-Supply Operation; (3)True Fail-Safe Receiver Input; (4)Available in μMAX Package; (5)1/8-Unit-Load Receiver Input; (6)-7V to +10V Common-Mode Input Voltage Range.
