Product Summary
The MB90F553APF is a general-purpose, high-performance, 16-bit microcontroller designed for applications which requires high-speed real-time processing, such as industrial machines, OA equipment, and process control systems. In addition, the MB90F553APF has an on-chip 32-bit accumulator which enables processing of long-word data.
Parametrics
MB90F553APF absolute maximum ratings: (1)Power supply voltage: VCC: VSS - 0.3 to VSS + 6.0 V; AVCC: VSS - 0.3 to VSS + 6.0 V at VCC = AVCC; AVRH: VSS - 0.3 to VSS + 6.0 V at AVCC ≥AVRH ≥AVRL; AVRH: VSS - 0.3 to VSS + 6.0 V at AVCC ≥AVRH ≥AVRL; (2)Input voltage, VI: VSS - 0.3 to VSS + 6.0 V; (3)Output voltage, VO: VSS - 0.3 to VSS + 6.0 V ; (4)L level maximum output current: IOL1: 10 mA max at Other than P20 to P27; IOL2: 20 mA max at P20 to P27; (5)L level average output current: IOLAV1: 4 mA max at Other than P20 to P27; IOLAV2: 12 mA at P20 to P27; (6)L level maximum total output current, sIOL:150 mA max; (7)L level average total output current, SIOLAV: 80 mA max; (8)H level maximum output current, IOH: -15 mA max; (9)H level average output current, IOHAV: -4 mA max; (10)H level maximum total output current, SIOH: -100 mA max; (11)H level average total output current, SIOHAV: -50 mA max; (12)Power consumption, PD: 500 mW max; (13)Operating temperature, TA: -40 to +85 ℃; (14)Storage temperature, Tstg: -55 to +150 ℃.
Features
MB90F553APF features: (1)Minimum instruction execution time: 62.5 ns (at oscillation of 4 MHz,×four times the PLL clock); (2)Maximum memory space 16 Mbytes; (3)Instruction set optimized for controller applications, Supported data types: Bit, byte, word and long word, Typical addressing mode: 23 types, Enhanced precision calculation realized by 32-bit accumulator, Enhanced signed multiplication/division instruction and RETI instruction functions.
