Product Summary
The PC28F640J3C115 is an Intel StrataFlash Memory. The PC28F640J3C115 contains high-density memories organized as 32 Mbytes or 16Mwords (256-Mbit, available on the 0.18μm lithography process only), 16 Mbytes or 8 Mwords(128-Mbit), 8 Mbytes or 4 Mwords (64-Mbit), and 4 Mbytes or 2 Mwords (32-Mbit). The PC28F640J3C115 can be accessed as 8- or 16-bit words. A 128-bit Protection Register has multiple uses, including unique flash device identification.
Parametrics
PC28F640J3C115 absolute maximum ratings: (1)Temperature under Bias Extended: –40 ℃ to +85 ℃; (2)Storage Temperature: –65 ℃ to +125 ℃; (3)Voltage On Any signal: –2.0 V to +5.0 V; (4)Output Short Circuit Current: 100 mA.
Features
PC28F640J3C115 features: (1)110/115/120/150 ns Initial Access Speed; (2)125 ns Initial Access Speed (256 Mbit density only); (3)25 ns Asynchronous Page mode Reads; (4)30 ns Asynchronous Page mode Reads(256Mbit density only); (5)32-Byte Write Buffer; (6)6.8 μs per byte effective programming time; (7)Program and Erase suspend support; (8)Flash Data Integrator (FDI), Common Flash Interface (CFI) Compatible; (9)Absolute Protection with VPEN = GND; (10)Individual Block Locking; (11)Block Erase/Program Lockout during Power Transitions.
Diagrams
 |
