Product Summary
The PCI6254-BB66BC is an Adaptive High Performance Asynchronous 66MHz, 64-bit, PCI–to–PCI Bridge designed for high performance, high availability applications in bus expansions, programmable data transfer rate control, frequency conversions from slower PCI to faster PCI buses or from faster PCI to slower PCI buses, address remapping, high availability hot swap, and universal system-to-system bridging. The PCI6254-BB66BC includes sophisticated buffer management and buffer configuration options designed to provide customizable performance.
Parametrics
PCI6254-BB66BC specifications: (1)PCI-PCI UNIVERSAL BRIDGE, 365PBGA; (2)PCI Bus Type: PCI to PCI Bridge; (3)Supply Voltage Range: 3.3V, 5V; (4)Operating Temperature Range: 0℃ to +70℃; (5)Digital IC Case Style: BGA; (6)No. of Pins: 365; (7)Bridge Type: PCI to PCI; (8)No. of Ports Max: 16; (9)Package / Case: PBGA; (10)Supply Voltage Max: 3.6V; (11)Supply Voltage Min: 3V; (12)Termination Type: SMD.
Features
PCI6254-BB66BC features: (1)64-bit, 33MHz-66MHz Asynchronous operation; (2)5V signal input tolerance and 5V signal to 3.3V signal conversions; (3)31mm × 31mm PBGA; (4)1KB FIFO size; (5)PCI Bus Types; (6)Transparent and Non-Transparent Bridge Function; (7)Support for 9 Bus Masters; (8)Usable in CPCI System Slot or Peripheral Slot.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 PCI6254-BB66BC |
PLX Technology |
Peripheral Drivers & Components (PCIs) 64-bit 66MHz BRIDGE |
Data Sheet |
|
|
||||||||||
 |
PCI6254-BB66BC G |
PLX Technology |
Peripheral Drivers & Components (PCIs) Dual Mode Universal PCI to PCI Bridge |
Data Sheet |
|
|
||||||||||
