SAF-C515-L24N

8-Bit CMOS Microcontroller, PLCC, – 0.5 V to 6.5 V, – 10 mA to 10 mA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.00~5.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $3.00~5.50

PartNumber:: SAF-C515-L24N

Brand:: Infineon Technologies AG - Infineon | Pack: PLCC | D/C: 06+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Lisa's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-04

From Other Seller

Part Number:SAF-C515-L24N
US $3.00 - 5.50
EKY-160ELL121MF11D

US $0.10 - 1.00 / Piece
(0) Remove
AT45DB161D-SU

US $1.50 - 3.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The SAF-C515-L24N is an 8-Bit CMOS Microcontroller. It provides ALE switch-off capability, on-chip emulation support, ROM protection, and slow down mode capability. With a maximum external clock rate of 24 MHz, the SAF-C515-L24N achieves a 500 ns instruction cycle time (1ms at 12 MHz). The SAF-C515-L24N is mounted in a P-MQFP-80 package.

Parametrics

SAF-C515-L24N absolute maximum ratings: (1)Ambient temperature under bias (TA): – 40 to 110℃; (2)Storage temperature (Tstg): – 65 to 150℃; (3)Voltage on VCC pins with respect to ground (VSS): – 0.5 V to 6.5 V; (4)Voltage on any pin with respect to ground (VSS): – 0.5 V to VCC +0.5 V; (5)Input current on any pin during overload: – 10 mA to 10 mA; (6)Absolute sum of all input currents during overload condition: 100 mA; (7)Power dissipation: TBD.

Features

SAF-C515-L24N features: (1)8-bit A/D converter: 8 multiplexed analog inputs; Programmable reference voltages; (2)16-bit watchdog timer; (3)Power saving modes: Idle mode; Slow down mode (can be combined with idle mode); Software power-down mode; (4)12 interrupt sources (7 external, 5 internal) selectable at four priority levels; (5)On-chip emulation support logic (Enhanced Hooks Technology TM); (6)ALE switch-off capability; (7)P-MQFP-80-1 package; (8)Temperature Ranges: TA = -40 to 85℃.
