Product Summary
The TPS71533DCKR is a low-dropout (LDO) voltage regulator. It offers the benefits of high input voltage, low-dropout voltage, low-power operation, and miniaturized packaging. The TPS71533DCKR, which operates over an input range of 2.5 V to 24 V, is stable with any capacitor ( ≥ 0.47 uF). The applications of the TPS71533DCKR are Ultra-Low Power Microcontrollers, Cellular/Cordless Handsets, Portable/Battery-Powered Equipment.
Parametrics
TPS71533DCKR absolute maximum ratings: (1)V IN range:-0.3 V to +24 V; (2)V OUT range:-0.3 V to +16.5 V; (3)Peak output current:Internally limited; (4)ESD rating, HBM:2 kV; (5)ESD rating, CDM:500 V; (6)Junction temperature range:-40 to +150℃; (7)Storage temperature range:-65 to +150℃.
Features
TPS71533DCKR features: (1)24-V Maximum Input Voltage; (2)Low 3.2- μA Quiescent Current at 50 mA; (3)Stable With Any Capacitor ( ≥ 0.47 μF); (4)50-mA Low-Dropout Regulator; (5)Available in 1.8 V, 1.9 V, 2.3 V, 2.5 V, 3.0 V, 3.3 V, 3.45 V, 5.0 V, and Adjustable (1.2 V to 15 V); (6)Minimum/Maximum Specified Current Limit; (7)5-Pin SC70/SOT-323 (DCK) Package; (8)–40 to +125℃ Specified Junction Temperature Range.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 TPS71533DCKR |
Texas Instruments |
Low Dropout (LDO) Regulators 50mA 3.3V HI LDO |
Data Sheet |
|
|
||||||||||||
|
TPS71533DCKRG4 |
Texas Instruments |
Low Dropout (LDO) Regulators 50-mA 3.3-V High Input Voltage |
Data Sheet |
|
|
||||||||||||
