Product Summary

The XC3S2000-4FGG900C is a Field-Programmable Gate Array. It is specifically designed to meet the needs of high volume, cost-sensitive consumer electronic applications. The eight-member family offers densities ranging from 50,000 to five million system gates. The XC3S2000-4FGG900C builds on the success of the earlier Spartan-IIE family by increasing the amount of logic resources, the capacity of internal RAM, the total number of I/Os, and the overall level of performance as well as by improving clock management functions. Numerous enhancements derive from the Virtex-II platform technology. The XC3S2000-4FGG900C enhancements, combined with advanced process technology, deliver more functionality and bandwidth per dollar than was previously possible, setting new standards in the programmable logic industry.

Parametrics

XC3S4000-4FGG676C absolute maximum ratings: (1)Internal supply voltage:–0.5V to 1.32V; (2)Auxiliary supply voltage:–0.5V to 3.00V; (3)Output driver supply voltage:–0.5V to 3.75V; (4)Input reference voltage:–0.5V to VCCO+0.5V; (5)Voltage applied to all User I/O pins and Dual-Purpose pins:–0.5V to VCCO+0.5V; (6)Voltage applied to all Dedicated pins:–0.5V to VCCAUX+0.5V; (7)Junction temperature:- 125℃; (9)Storage temperature:–65℃ to 150℃.

Features

XC3S4000-4FGG676C features: (1)Revolutionary 90-nanometer process technology; (2)Very low cost, high-performance logic solution for high-volume, consumer-oriented applications; (3)SelectIO signaling; (4)Logic resources; (5)SelectRAM hierarchical memory; (6)Digital Clock Manager (up to four DCMs); (7)Eight global clock lines and abundant routing; (8)Fully supported by Xilinx ISE development system - Synthesis, mapping, placement and routing; (9)MicroBlaze processor, PCI, and other cores.

Diagrams

XC3S4000-4FGG676C diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
XC3S2000-4FGG900C
XC3S2000-4FGG900C


SPARTAN-3A FPGA 2M STD 900-FBGA

Data Sheet

0-27: $51.12
Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
XC3S1000
XC3S1000

Other


Data Sheet

Negotiable
XC3S1000-4FG676I
XC3S1000-4FG676I


IC FPGA SPARTAN 3 676FBGA

Data Sheet

0-40: $51.36
XC3S1000-4FGG320C
XC3S1000-4FGG320C


SPARTAN-3A FPGA 1M STD 320-FBGA

Data Sheet

0-84: $26.16
XC3S1000-4FGG320I
XC3S1000-4FGG320I


IC SPARTAN-3A FPGA 1M 320-FBGA

Data Sheet

0-84: $30.09
XC3S1000-4FGG456I
XC3S1000-4FGG456I


SPARTAN-3A FPGA 1M STD 456-FBGA

Data Sheet

0-60: $37.26
XC3S1000-4FGG676C
XC3S1000-4FGG676C


IC SPARTAN-3 FPGA 1M 676-FBGA

Data Sheet

0-1: $51.36
1-25: $44.67
25-100: $38.85
