XC5VLX110T-2FFG1136C

Product Summary

The XC5VLX110T-2FFG1136C is an FPGA. The XC5VLX110T-2FFG1136C is available in -3, -2, -1 speed grades, with -3 having the highest performance. The XC5VLX110T-2FFG1136C contains many hard-IP system level blocks, including powerful 36-Kbit block RAM/FIFOs, second generation 25 x 18 DSP slices, SelectIO technology with built-in digitally-controlled impedance, ChipSync source-synchronous interface blocks, system monitor functionality, enhanced clock management tiles with integrated DCM (Digital Clock Managers) and phase-locked-loop (PLL) clock generators, and advanced configuration options.

Parametrics

XC5VLX110T-2FFG1136C absolute maximum ratings: (1)Internal supply voltage relative to GND:–0.5 to 1.1 V; (2)Auxiliary supply voltage relative to GND:–0.5V to 3.0V; (3)Output drivers supply voltage relative to GND:–0.5V to 3.75V; (4)Key memory battery backup supply:–0.5V to 4.05V; (5)Input reference voltage:–0.5V to 3.75V; (6)3.3V I/O input voltage relative to GND(user and dedicated I/Os):–0.75V to 4.05V; (7)3.3V I/O input voltage relative to GND (restricted to maximum of 100 user I/Os):–0.95V to 4.4V (Commercial Temperature),-0.85V to 4.3V(Industrial Temperature); (8)2.5V or below I/O input voltage relative to GND (user and dedicated I/Os):–0.75V to VCCO + 0.5V; (9)Current applied to an I/O pin, powered or unpowered:±100 mA; (10)Total current applied to all I/O pins, powered or unpowered:±100 mA; (11)Voltage applied to 3-state 3.3V output(user and dedicated I/Os):–0.75V to 4.05V; (12)Voltage applied to 3-state 2.5V or below output (user and dedicated I/Os):–0.75V to VCCO + 0.5V; (13)Storage temperature (ambient):–65℃ to 150℃; (14)Maximum soldering temperature:+220℃; (15)Maximum junction temperature:+125℃.

Features

XC5VLX110T-2FFG1136C features: (1)Real 6-input look-up table (LUT) technology; (2)Dual 5-LUT option; (3)Improved reduced-hop routing; (4)64-bit distributed RAM option; (5)SRL32/Dual SRL16 option; (6)1.2 to 3.3V I/O Operation; (7)Source-synchronous interfacing using ChipSync technology; (8)Digitally-controlled impedance (DCI) active termination; (9)Flexible fine-grained I/O banking; (10)High-speed memory interface support; (11)65-nm copper CMOS process technology; (12)1.0V core voltage; (13)High signal-integrity flip-chip packaging available in standard or Pb-free package options; (14)FXT Platform only; (15)RISC architecture; (16)7-stage pipeline; (17)32-Kbyte instruction and data caches included; (18)Optimized processor interface structure (crossbar); (19)25 x 18, two’s complement, multiplication; (20)Optional adder, subtracter, and accumulator; (21)Optional pipelining; (22)Optional bitwise logical functionality; (23)Dedicated cascade connections.
