Product Summary
The AD396TD is a high-speed microp 14-bit, low power multiplying digital-to-analog converter followed by precision voltage output amplifiers all in a compact 28-pin hybrid package. The design is based on a proprietary latched 14-bit CMOS DAC chip which reduces chip count and provides high reliability. The AD396TD (K, T) is laser-trimmed to ±1LSB max differ ±0.05 p at 25℃. The high initial accuracy is made possible by the use of precision laser trimmed thin-film scaling resistors.
Parametrics
AD396TD absolute maximum ratings: (1)+VS to DGND: -0.3V to +17V; (2)-VS to DGND: +0.3V to -17V; (3)Digital inputs to DGND: -0.3V to +7V; (4)VREDIN to DGND: ±25V; (5)AFND to DGND: +0.3V to +VS; (6)Analog outputs: Indefinite short to AGND or DGND Momentary short to ±VS.
Features
AD396TD features: (1)Four, Pre-Trimmedr 14-Bit CMOS DACs; (2)Double Buffered for Simultaneous Update; (3)Precision Output Amplifiers for Voltage Out; (4)Full Four Quadrant Multiplication - Independently Pinned Out DAC Reference; (5)Monotonicity Guaranteed Over Full MIL Temp. Range; (6)Low Power - 780mW Max; (7)Small 28 Lead, Hermetic Double DIP Package; (8)MKL-STD-883 Processing Available.
Diagrams
 |
