Product Summary
The AM29LV065DU-90REI is a 64 Mbit, 3.0 Volt (3.0 V to 3.6 V) single power supply flash memory device, which is organized as 8,388,608 bytes. Data appears on DQ0-DQ7. The AM29LV065DU-90REI is designed to be programmed in-system with the standard system 3.0 volt VCC supply. A 12.0 volt VPP is not required for program or erase operations. The AM29LV065DU-90REI can also be programmed in standard EPROM programmers.
Parametrics
AM29LV065DU-90REI absolute maximum ratings: (1)Plastic Packages: –65℃ to +150℃; (2)Ambient Temperature with Power Applied: –65℃ to +125℃; (3)Voltage with Respect to Ground: VCC: –0.5 V to +4.0 V, VIO: –0.5 V to +5.5 V, A9, OE#, ACC, and RESET#: –0.5 V to +12.5 V, All other pins: –0.5 V to VCC +0.5 V; (4)Output Short Circuit Current: 200 mA.
Features
AM29LV065DU-90REI features: (1)Single power supply operation: 3.0 to 3.6 volt read, erase, and program operations; (2)VersatileIOTM control: Device generates output voltages and tolerates input voltages on the DQ I/Os as determined by the voltage on VIO input; (3)High performance: Access times as fast as 90 ns; (4)Manufactured on 0.23 μm process technology; (5)CFI (Common Flash Interface) compliant: Provides device-specific information to the system, allowing host software to easily reconfigure for different Flash devices; (6)SecSi (Secured Silicon) Sector region: 256-byte sector for permanent, secure identification through an 16-byte random Electronic Serial Number, May be programmed and locked at the factory or by the customer, Accessible through a command sequence.
Diagrams
 |
