LTC1663CMS8#PBF

10BIT, Rail-to-Rail Micropower DAC, 8-MSOP, 2.7V to 5.5V, 60μA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~2.00

PartNumber:: LTC1663CMS8#PBF

Brand:: Linear Technology - Linear | Pack: DIP | D/C: 08+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Lisa's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-27

From Other Seller

Part Number:LTC1663CMS8#PBF
US $1.00 - 2.00
iphone5 data cable

US $4.00 - 5.00 / Piece
(0) Remove
HEF4093BT

US $0.15 - 1.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LTC1663CMS8#PBF is a 10-Bit Rail-to-Rail Micropower DAC with 2-Wire Interface. It operates from a single supply with a range of 2.7V to 5.5V. The reference for the LTC1663CMS8#PBF is selectable between the supply voltage or an internal bandgap reference. Selecting the internal bandgap reference will set the full-scale output voltage range to 2.5V. Selecting the supply as the reference sets the output voltage range to the supply voltage. The applications of the LTC1663CMS8#PBF include: Digital Calibration, Offset/Gain Adjustment, Industrial Process Control, Automatic Test Equipment, Arbitrary Function Generators, Battery-Powered Data Conversion Products.

Parametrics

LTC1663CMS8#PBF absolute maximum ratings: (1)VCC to GND: – 0.3V to 7.5V; (2)SDA, SCL: –0.3V to 7.5V; (3)AD0, AD1, AD2 (MSOP Only): –0.3V to (VCC + 0.3V); (4)VOUT: –0.3V to (VCC + 0.3V); (5)Operating Temperature Range: 0℃ to 70℃; (6)Storage Temperature Range: – 65℃ to 150℃; (7)Lead Temperature (Soldering, 10 sec): 300℃.

Features

LTC1663CMS8#PBF features: (1)Micropower 10-Bit DAC in SOT-23; (2)Low Operating Current: 60μA; (3)Ultralow Power Shutdown Mode: 10μA; (4)2-Wire Serial Interface Compatible with SMBus and I2C; (5)Single 2.7V to 5.5V Operation; (6)Selectable Internal Reference or Ratiometric to VCC; (7)Buffered True Rail-to-Rail Voltage Output; (8)Maximum DNL Error: 0.75LSB; (9)Power-On Reset; (10)8 User Selectable Addresses (MSOP Package); (11)0.6V VIL and 1.4V VIH for SDA and SCL; (12)Small 5-Lead SOT-23 and 8-Lead MSOP Packages.
