LTM4601EV#PBF

complete 12A step-down switch mode, DC/DC μModule, 118-LGA, 0.6V to 5V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $11.70~13.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $11.70~13.00

PartNumber:: LTM4601EV#PBF

Brand:: Linear Technology - Linear | Pack: LGA | D/C: 08+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Lisa's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-12-16

From Other Seller

Part Number:LTM4601EV#PBF
US $11.70 - 13.00
CM2030-A0TR

US $0.92 - 2.50 / Piece
(0) Remove
QM75DY-H

US $16.00 - 30.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LTM4601EV#PBF is a complete 12A step-down switch mode DC/DC power supply with onboard switching controller, MOSFETs, inductor and all support components. The μModuleTM is housed in a small surface mount 15mm ×15mm × 2.8mm LGA package. Operating over an input voltage range of 4.5 to 20V, the LTM4601EV#PBF supports an output voltage range of 0.6V to 5V as well as output voltage tracking and margining. The high efficiency design delivers 12A continuous current (14A peak). Only bulk input and output capacitors are needed to complete the design. The applications of the LTM4601EV#PBF include Telecom and Networking Equipment, Servers, Industrial Equipment, Point of Load Regulation.

Parametrics

LTM4601EV#PBF absolute maximum ratings: (1)INTVCC, DRVCC, VOUT_LCL, VOUT (VOUT ≤ 3.3V with; (2)DIFFVOUT): –0.3V to 6V; (3)PLLIN, TRACK/SS, MPGM, MARG0, MARG1, PGOOD, fSET: –0.3V to INTVCC + 0.3V; (4)RUN: –0.3V to 5V; (5)VFB, COMP: –0.3V to 2.7V; (6)VIN: –0.3V to 20V; (7)VOSNS+, VOSNS–: –0.3V to INTVCC – 1V; (8)Operating Temperature Range: –40℃ to 85℃; (9)Junction Temperature: 125℃; (10)Storage Temperature Range: –55℃ to 125℃.

Features

LTM4601EV#PBF features: (1)Complete Switch Mode Power Supply; (2)Wide Input Voltage Range: 4.5V to 20V; (3)12A DC Typical, 14A Peak Output Current; (4)0.6V to 5V Output Voltage; (5)Output Voltage Tracking and Margining; (6)Parallel Multiple μModules for Current Sharing; (7)Differential Remote Sensing for Precision Regulation; (8)PLL Frequency Synchronization; (9)±1.5% Regulation; (10)Current Foldback Protection (Disabled at Start-Up); (11)Pb-Free (e4) RoHS Compliant Package with Gold Finish Pads; (12)Ultrafast Transient Response; (13)Current Mode Control; (14)Up to 95% Efficiency at 5VIN, 3.3VOUT; (15)Programmable Soft-Start; (16)Output Overvoltage Protection; (17)Small Footprint, Low Profile (15mm × 15mm × 2.8mm) Surface Mount LGA Package.
