PA28F200BVT60

boot block flash memory, 60mA, 44-Lead PSOP, 3.0 V to 3.6 V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~2.00

PartNumber:: PA28F200BVT60

Brand:: Intel Corporation - Intel | Pack: SOP | D/C: 04+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Lisa's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-28

From Other Seller

Part Number:PA28F200BVT60
US $1.00 - 2.00
iphone5 data cable

US $4.00 - 5.00 / Piece
(0) Remove
IRF9540NPBF

US $0.50 - 3.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The PA28F200BVT60 is a 2-mbit smartvoltage boot block flash memory. It offers 3.0 V–3.6 V operation and also operates at 5 V for high-speed access times. Throughout this datasheet, the PA28F200BVT60 refers to all x8/x16 2-Mbit products, while it refers to all x8 2-Mbit boot block products.

Parametrics

PA28F200BVT60 absolute maximum ratings: (1)Commercial Operating Temperature During Read: 0 ℃ to +70 ℃, During Block Erase and Word/Byte Program: 0 ℃ to +70 ℃, Temperature Under Bias: –10 ℃ to +80 ℃; (2)Extended Operating Temperature During Read: –40 ℃ to +85 ℃, During Block Erase and Word/Byte Program: –40 ℃ to +85 ℃, Temperature Under Bias: –40 ℃ to +85 ℃; (3)Storage Temperature: –65 ℃ to +125 ℃; (4)Voltage on Any Pin(except VCC, VPP, A9 and RP#) with Respect to GND: –2.0 V to +7.0 V; (5)Voltage on Pin RP# or Pin A9 with Respect to GND: –2.0 V to +13.5 V; (6)VPP Program Voltage with Respect to GND during Block Erase and Word/Byte Program: –2.0 V to +14.0 V; (7)VCC Supply Voltage with Respect to GND: –2.0 V to +7.0 V; (8)Output Short Circuit Current: 100 mA.

Features

PA28F200BVT60 features: (1)Intel SmartVoltage Technology; (2)Very High-Performance Read; (3)Low Power Consumption; (4)x8/x16-Selectable Input/Output Bus; (5)x8-Only Input/Output Architecture; (6)Optimized Array Blocking Architecture; (7)Extended Temperature Operation -40 ℃ to +85 ℃; (8)Extended Block Erase Cycling; (9)Automated Word/Byte Program and Block Erase; (10)SRAM-Compatible Write Interface; (11)Automatic Power Savings Feature; (12)Reset/Deep Power-Down Input.
