S29GL128P10FFI010

Mirrorbit Flash product, 3.0 Volt, 128M, 64FBGA, S29GL128P10FFI010

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~2.00

PartNumber:: S29GL128P10FFI010

Brand:: SPANSION - spansion | Pack: BGA | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Lisa's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-28

From Other Seller

Part Number:S29GL128P10FFI010
US $1.00 - 2.00
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
AT25256AW-10SU-2.7

US $0.65 - 1.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The S29GL128P10FFI010 is a Mirrorbit Flash product fabricated on 90 nm process technology. It offers a fast page access time of 25 ns with a corresponding random access time as fast as 90 ns. The S29GL128P10FFI010 features a Write Buffer that allows a maximum of 32 words/64 bytes to be programmed in one operation, resulting in faster effective programming time than standard programming algorithms. This makes the S29GL128P10FFI010 ideal for today’s embedded applications that require higher density, better performance and lower power consumption.

Parametrics

S29GL128P10FFI010 absolute maximum ratings: (1)Storage Temperature, Plastic Packages: -65℃ to +150℃; (2)Ambient Temperature with Power Applied: -65℃ to +125℃; (3)Voltage with Respect to Ground: All Inputs and I/Os except as noted below: -0.5 V to VCC + 0.5 V, VCC: -0.5 V to +4.0 V, VIO: -0.5V to +4.0V, A9 and ACC: -0.5 V to +12.5 V; (4)Output Short Circuit Current: 200 mA.

Features

S29GL128P10FFI010 features: (1)Single 3V read/program/erase (2.7-3.6 V); (2)Enhanced VersatileI/O control; (3)90 nm MirrorBit process technology; (4)8-word/16-byte page read buffer; (5)32-word/64-byte write buffer reduces overall programming time for multiple-word updates; (6)Secured Silicon Sector region; (7)Uniform 64Kword/128KByte Sector Architecture; (8)100,000 erase cycles per sector typical; (9)20-year data retention typical; (10)Offered Packages: 56-pin TSOP, 64-ball Fortified BGA; (11)Suspend and Resume commands for Program and Erase operations; (12)Write operation status bits indicate program and erase operation completion; (13)Unlock Bypass Program command to reduce programming time; (14)Support for CFI (Common Flash Interface); (15)Persistent and Password methods of Advanced Sector Protection.
