SN74SSTU32864CZKER

25-bit configurable registered buffer, 96-BGA, 1.7V to 1.9V, ±50 mA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~2.00

PartNumber:: SN74SSTU32864CZKER

Brand:: Texas Instruments - TI | Pack: BGA | D/C: 07+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Lisa's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-06-09

From Other Seller

Part Number:SN74SSTU32864CZKER
US $1.00 - 2.00
iphone5 data cable

US $4.00 - 5.00 / Piece
(0) Remove
HEF4051BT

US $0.15 - 1.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The SN74SSTU32864CZKER is a 25-bit configurable registered buffer with sstl_18 inputs and outputs. It is designed for 1.7-V to 1.9-V VCC operation. In the 1:1 pinout configuration, only one device per DIMM is required to drive nine SDRAM loads. In the 1:2 pinout configuration, two devices per DIMM are required to drive 18 SDRAM loads. The SN74SSTU32864CZKER operates from a differential clock (CLK and CLK). Data are registered at the crossing of CLK going high and CLK going low. The SN74SSTU32864CZKER supports low-power standby operation. When RESET is low, the differential input receivers are disabled, and undriven (floating) data, clock, and reference voltage (VREF) inputs are allowed. In addition, when RESET is low, all registers are reset and all outputs are forced low.

Parametrics

SN74SSTU32864CZKER absolute maximum ratings: (1)Supply voltage range, VCC: –0.5 V to 2.5 V; (2)Input voltage range, VI: –0.5 V to 2.5 V; (3)Output voltage range, VO: –0.5 V to VCC + 0.5 V; (4)Input clamp current, IIK (VI < 0 or VI > VCC): ±50 mA; (5)Output clamp current, IOK (VO < 0 or VO > VCC): ±50 mA; (6)Continuous output current, IO (VO = 0 to VCC): ±50 mA; (7)Continuous current through each VCC or GND: ±100 mA; (8)Package thermal impedance, θJA: 36℃/W; (9)Storage temperature range, Tstg: –65℃ to 150℃.

Features

SN74SSTU32864CZKER features: (1)Member of the Texas Instruments Widebus Family; (2)Pinout Optimizes DDR-II DIMM PCB Layout; (3)Configurable as 25-Bit 1:1 or 14-Bit 1:2 Registered Buffer; (4)Chip-Select Inputs Gate the Data Outputs from Changing State and Minimizes System Power Consumption; (5)Output Edge-Control Circuitry Minimizes Switching Noise in an Unterminated Line; (6)Supports SSTL_18 Data Inputs; (7)Differential Clock (CLK and CLK) Inputs.
