STV0299BL

CMOS single-chip multistandard demodulator, TQFP64, ± 45 mhz

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~2.00

PartNumber:: STV0299BL

Brand:: STMicroelectronics - ST | Pack: QFP | D/C: 06+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Lisa's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-30

From Other Seller

Part Number:STV0299BL
US $1.00 - 2.00
ECA1HHG4R7

US $10.00 - 10.00 / Piece
(0) Remove
74AHC2G08VS SOP-8

US $2.00 - 2.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The STV0299BL is a CMOS single-chip multistandard demodulator for digital satellite broadcasting. The STV0299BL consists of two A/D converters for I-input and Q-input, a multistandard QPSK and BPSK demodulator, and a forward error correction (FEC) unit having both an inner(Viterbi) and outer (Reed-Solomon) decoder. The STV0299BL integrates a derotator before the Nyquist root filter, allowing a wide range of offset tracking. It is used in digital satellite receiver and set-top boxes.

Parametrics

STV0299BL absolute maximum ratings: (1)VDD_3.3 V Pad Power Supply Voltage: 4.0 V; (2)VDD Core Level Power Supply Voltage: 3.0 V; (3)VI Voltage on Input Pins: -0.5, VDD_3.3 V + 0.5 V; (4)VO Voltage on Output Pins: -0.5, VDD_3.3 V + 0.5 V; (5)Tstg Storage Temperature: -40, +150 ℃; (6)Toper Operating Ambient Temperature: -10, +70 ℃; (7)Tj Junction Temperature: +125 ℃.

Features

STV0299BL features: (1)multistandard qpsk and bpsk demodulation; (2)easy implementation with low cost direct conversion tuners; (3)extremely low ber when co-channel interference; (4)wide carrier loop tracking range to compensate for dish frequency drift; (5)common interface compliant; (6)very low power consumption; (7)integrated dual 6-bit analog to digital converters; (8)dual digital agc; (9)digital nyquist root filter with roll-off of 0.35 or 0.20; (10)digital carrier loop with lock detector, on-chip wide range derotator and tracking loop(typ ± 45 mhz); (11)digital timing recovery with lock detector; (12)channel bit rate up to 90 mbps and symbol frequency rate from 1 to 50 msymbols.
