Product Summary
The IC41LV16100S-50TG is a 1,048,576 x 16-bit high-performance CMOS Dynamic Random Access Memory. The IC41LV16100S-50TG offers an accelerated cycle access called EDO Page Mode. EDO Page Mode allows 1,024 random accesses within a single row with access cycle time as short as 20 ns per 16-bit word. The IC41LV16100S-50TG is ideally suited for high-bandwidth graphics, digital signal processing, high-performance computing systems, and peripheral applications.
Parametrics
IC41LV16100S-50TG absolute maximum ratings: (1)Voltage on Any Pin Relative to GND:–1.0 to +7.0V or –0.5 to +4.6V; (2)Supply Voltage: -1.0 to +7.0V or –0.5 to +4.6V; (3)Output Current:50 mA; (4)Power Dissipation:1 W; (5)Commercial Operation Temperature:0 to +70℃; (6)Industrial Operationg Temperature:–40 to +85℃; (7)Storage Temperature:–55 to +125℃.
Features
IC41LV16100S-50TG features: (1)Extended Data-Out (EDO) Page Mode access cycle; (2)TTL compatible inputs and outputs; tristate I/O; (3)Refresh Interval: Refresh Mode: 1,024 cycles /16 ms, RAS-Only, CAS-before-RAS (CBR), and Hidden, Self refresh Mode - 1,024 cycles / 128ms, JEDEC standard pinout; (4)Single power supply:3.3V±10%; (5)Byte Write and Byte Read operation via two CAS; (6)Industrail Temperature Range -40 to 85℃.
Diagrams
 |
